Mitsubishi Q2ACPU

22 - 34
22. TROUBLE SHOOTING
4102
[OPERATION ERROR]
• The network No. or station No. specified for the
dedicated instruction is wrong.
• The link direct device (J \ ) setting is incorrect.
• The module No./ network No./number of
character strings exceeds the range that can be
specified.
■Collateral informationmmon
• Common Information:Program error location
• Individual Information:–
■Diagnostic Timing
• When instruction executed
Read the common information of the error using
the peripheral device, check error step
corresponding to its numerical value (program error
location), and correct the problem.
RUN:
Off/On
ERR.:
Flicker/On
CPU Status:
Stop/
Continue
*1
QnA
4103
[OPERATION ERROR]
The configuration of the PID dedicated instruction
is incorrect.
■Collateral informationmmon
• Common Information:Program error location
• Individual Information:–
■Diagnostic Timing
• When instruction executed
4104
[OPERATION ERROR]
The number of settings is beyond the range.
■Collateral informationmmon
• Common Information:Program error location
• Individual Information:–
■Diagnostic Timing
• When instruction executed
Read the common information of the error using
peripheral device, and check and correct the
program corresponding to that value (program error
location).
Q4AR
4107
[OPERATION ERROR]
Numbers of execution to the CC-Link instruction
are beyond 32.
■Collateral informationmmon
• Common Information:Program error location
• Individual Information:–
■Diagnostic Timing
• When instruction executed
Set the numbers of execution to the CC-Link
instruction to 32 or less.
QnA
4108
[OPERATION ERROR]
The CC-Link parameter is not set when the CC-
Link instruction is executed.
■Collateral informationmmon
• Common Information:Program error location
• Individual Information:–
■Diagnostic Timing
• When instruction executed
Execute the CC-Link instruction after setting the
CC-Link parameter.
4200
[FOR NEXT ERROR]
No NEXT instruction was executed following the
execution of a FOR instruction.
Alternatively, there are fewer NEXT instructions
than FOR instructions.
■Collateral informationmmon
• Common Information:Program error location
• Individual Information:–
■Diagnostic Timing
• When instruction executed
Read the common information of the error using
the peripheral device, check error step
corresponding to its numerical value (program error
location), and correct the problem.
RUN:
Off
ERR.:
Flicker
CPU Status:
Stop
Error
Code
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
*1 CPU operation can be set in the parameters at error occurrence. (LED indication varies.)
