Mitsubishi Q2ACPU User Manual

3 - 8
3. SYSTEM CONFIGURATION
Output module
AY10 16-output relay contact output module (2A) 16 (16 outputs) 0.115 0.15
The short
protection and
overheat
protection
functions of the
AY40P, AY41P,
AY60EP,
AY80EP,
AY81EP, and
AY82EP are
described
below:
Function that
protects the
transistors from
overcurrents
occurring, for
example, due to
short circuits in
external wiring.
Function that
protects the
transistors from
damage due to
external
temperature rise
attributable to
external causes.
AY10A
16-output relay contact output module,
for independent contact output
16 (16 outputs) 0.115 0.15
AY11
16-output relay contact output module,
with surge suppressor
16 (16 outputs) 0.115 0.15
AY11A
16-output relay contact output module, for
independent contact output, with surge
suppressor
16 (16 outputs) 0.115 0.15
AY11AEU
16-output relay contact output module, for
independent contact output, with surge
suppressor
16 (16 outputs) 0.115 0.15
AY11E
16-output relay contact output module
(fused)
16 (16 outputs) 0.115 0.15
AY11EEU
16-output relay contact output module
(fused)
16 (16 outputs) 0.115 0.15
AY13 32-point relay contact output module (2A) 32 (32 outputs) 0.23 0.29
AY13E 32-point relay contact output module 32 (32 outputs) 0.23 0.29
AY13EU
32-output relay contact output module
(fused)
32 (32 outputs) 0.23 0.29
AY15EU
24-point relay contact output module (2A)
CE-compliant
32 (32 outputs) 0.15 0.22
AY22
16-point triac output module
(2A, fused)
16 (16 outputs) 0.305 –
AY23
32-point triac output module
(0.6A, fused)
32 (32 outputs) 0.59 –
AY40
16-output 12/24VDC transistor output module
(0.1A)
16 (16 outputs) 0.115 0.016
AY40A
16-point 12/24VDC transistor output module,
for independent contact output (0.3A)
16 (16 outputs) 0.19 –
AY41
32-output 12/24VDC transistor output module
(0.1A)
32 (32 outputs) 0.23 0.04
AY42
64-output 12/24VDC transistor output module
(0.1A)
64 (64 outputs) 0.29 0.08
AY42-S1
64-output 12/24VDC transistor output module
(0.1A)
64 (64 outputs) 0.29 0.08
AY42-S3
64-output 12/24 VDC transistor output module
(fused)
64 (64 outputs) 0.29 0.08
AY42-S4
64-output 12/24VDC transistor output module,
zener diode with built-in photocoupler
64 (64 outputs) 0.50 –
Product Name Model Name Description
Number of Occupied
Points (points)
[I/O Allocation
Module Type]
Current Consumption
Remark
5VDC(A) 24VDC(A)
Short protection
function
Overheat
protection
function
