3. SYSTEM CONFIGURATION
Output module
AY50
16-point 12/24VDC transistor output module
(0.5A, fused)
16 (16 outputs) 0.115 0.13
*1: Indicates a
source load
module.
Other modules
are sink load
modules.
The short
protection and
overheat
protection
functions of the
AY40P, AY41P,
AY60EP,
AY80EP,
AY81EP, and
AY82EP are
described
below:
Function that
protects the
transistors from
overcurrents
occurring, for
example, due to
short circuits in
external wiring.
Function that
protects the
transistors from
damage due to
external
temperature rise
attributable to
external causes.
AY51
32-output 12/24VDC transistor output module
(0.5A)
32 (32 outputs) 0.23 0.10
AY51-S1
32-point 12/24VDC transistor output module
(0.3A, fused)
32 (32 outputs) 0.31 0.02
AY60
16-output 12/24/48VDC transistor output
module (2A, fused)
16 (16 outputs) 0.115 0.13
AY60S
16-output 12/24/48VDC
transistor output module (2A)
16 (16 outputs) 0.075 0.006
AY60EP
*1
16-output 12/24 VDC transistor output module
(2A), with short protection function and
overheat protection function
16 (16 outputs) 0.115 0.22
AY70
16-output, CMOS (5/12VDC) output module
(16mA)
16 (16 outputs) 0.10
12VDC
0.11
AY71
32-output, CMOS (5/12VDC) output module
(16mA)
32 (32 outputs) 0.20
12VDC
0.20
AY72
64-output, CMOS (5/12VDC) output module
(16mA)
64 (64 outputs) 0.30
12VDC
0.60
AY80
*1
16-output 12/24/48VDC transistor output
module (0.5A, fused)
16 (16 outputs) 0.115 0.12
AY81
*1
32-output 12/24VDC transistor output module
(0.5A)
32 (32 outputs) 0.23 0.10
AY82EP
*1
64-output 12/24VDC transistor output module
(0.1A), with short protection function and
overheat protection function
64 (64 outputs) 0.29 0.10
Dynamic input/
output
combination
module
A42XY 64 inputs, 64 outputs, dynamic scanning mode 64 (64 outputs) 0.11 0.235
Performs I/O
processing in 8-
point units
independently
of the CPU
module, while
scanning.
Input/output
combination
module
AH42
32 inputs, 32 outputs, 12/24VDC transistor
output module (0.1A)
64 (64 outputs) 0.245 0.04
The first half 32
points are inputs
and the second
half 32 points
are outputs.
Product Name Model Name Description
Number of Occupied
Points (points)
[I/O Allocation
Module Type]
Current Consumption
Remark
5VDC(A) 24VDC(A)
Short protection
function
Overheat
protection
function
