App - 3
APPENDICES
(3) Output instructions
* When specifying input (X) for the target device, specify the device number out of the actual
input (X) range.
(4) Shift instructions
(5) Master control instructions
Classification Symbol Description
Output
• Device output
• Sets a device.
*
• Resets a device.
• Generates one-program cycle pulse at the rising edge of an input
signal.
• Generates one-program cycle pulse at the falling edge of an input
signal.
• Inverts device output.
• Converts a direct output to pulse.
Classification Symbol Description
Shift • Shifts a device 1 bit.
Classification Symbol Description
Master control
• Master control start
• Master control reset
