3. SYSTEM CONFIGURATION
Special function module
D/A
converter
module
A68DAV
0 to 10V, analog output, 8 channels.
32 (special 32 points) 0.15 0.5
A68DAI-S1 0 to 20mA, analog output, 8 channels. 32 (special 32 points) 0.15 0.4
A62DA
4 to 20mA/0 to 10V
Analog output 12 bits, 2 channels
32 (special 32 points) 0.6 0.35
A62DA-S1
4 to 20mA/0 to 10V Analog output,
2 channels
A616DAI
4 to 20mA. Resolution: 1/4000
Analog output, 16 channels
32 (special 32 points) 0.3 –
15VDC (A68P)
is
required.
A616DAV
0 to 10 V/0 to 5 V. Resolution: 1/4000
Analog output, 16 channels
32 (special 32 points) 0.38 –
15VDC (A68P)
is
required.
Memory
card,
Centronics
interface
module
AD59
32k byte-memory battery backup
Can be connected to printer conforming to
Centronics standards
32 (special 32 points)
0.3
–
AD59-S1
0.32
0.35A when
connected to
AD59MEF.
Voice output
module
A11VC
Messages can be recorded and played back on
a maximum of 60 channels.
The following recording times can be selected
for each channel: 1 second, 2 seconds,
4 seconds, 8 seconds.
The total recording time is 64 seconds
16 (special 16 points) 0.6 0.38
Network
module
AJ71QLP21
For MELSECNET/10 optical loop networks
(compatible with SI cable)
32 (special 32 points) 0.65 –
• For Use with
QnACPU
Only
• Maximum 4
modules can
be used for
one CPU
module.
(Refer to
Section 3.3.2 )
AJ71QLP21G
For MELSECNET/10 optical loop network
(compatible with GI cable)
AJ71QLP21S
For MELSECNET/10 optical loop networks.
Network backup by external power supply
32 (special 32 points) 0.65 0.2
AJ71QBR11 For MELSECNET/10 coaxial bus networks
32 (special 32 points)
0.8
–
AJ71QLR21 For MELSECNET/10 coaxial loop network 1.14
AJ72QLP25
For MELSECNET/10 optical loop network
remote I/O stations (compatible with SI cable)
–0.8–
AJ72QLP25G
For MELSECNET/10 optical loop network
remote I/O station (compatible with GI cable)
AJ72QBR15
For MELSECNET/10 coaxial bus network
remote I/O stations
–
0.9
–
AJ72QLR25
For MELSECNET/10 coaxial loop network
remote I/O station
1.3
Product Name Model Name Description
Number of Occupied
Points (points)
[I/O Allocation
Module Type]
Current Consumption
Remark
5VDC(A) 24VDC(A)
+0.53A
-0.125A
+0.2A
-0.17A
