3 - 11
3. SYSTEM CONFIGURATION
Special function module
High-speed
counter
module
AD61
24-bit binary, 1/2 phase input,
reversible counter,
50kPPS, 2 channels
32 (special 32 points) 0.3 –
AD61S1
24-bit binary, 1/2 phase input,
reversible counter,
1 phase 10kPPS, 2 phases 7kPPS,
2 channels
32 (special 32 points) 0.3 –
A/D
converter
module
A68AD
4 to 20mA/0 to 10V,
Analog input, 8 channels
32 (special 32 points) 0.9 –
A68AD-S2
A68ADN
0 to 20mA/0 to 10V,
Analog input, 8 channels
32 (special 32 points) 0.4 –
A616AD
4 to 20mA/0 to 10V,
Analog input, 16 channels
Expansion to maximum of 121 channels
possible by using A60MX(R)
32 (special 32 points) 1.0 –
A60MX
Multiplex module (IC relay)
Analog input, 16 channels
16 (empty 16 points) 0.65 –
Used in
combination
with A616AD or
A616TD.
A60MXR
Multiplex module (mercury relay)
Analog input, 16 channels
16 (empty 16 points) 0.5 –
A60MXRN
Multiplex module (photo MOS relay)
Analog input, 16 channels
16 (empty 16 points) 0.35 –
Temperature
digital
converter
module
A616TD
For temperature detection by thermocouple
(when connected to A60MXT).
0 to 10V/0 to 20mA (when connected to
A60MX(R))
32 (special 32 points) 1.0 –
A60MXT
Multiplex module (mercury relay)
Temperature input: 15 channels.
Temperature detection by thermocouple when
used in combination with A616TD.
32
0.8 –
Used in
combination
with A616TD.
A60MXTN
Multiplex module (photo MOS relay)
Temperature input: 15 channels.
Temperature detection by thermocouple when
used in combination with A616TD.
32
0.64 –
A68RD3
-180 to 600 temperature input module
(For 3-wire type platinum resistor)
32 (special 32 points)
0.94 –
A68RD4
-180 to 600 temperature input module
(For 4-wire type platinum resistor)
0.75 –
Product Name Model Name Description
Number of Occupied
Points (points)
[I/O Allocation
Module Type]
Current Consumption
Remark
5VDC(A) 24VDC(A)
First half:
empty 16 points
Second half:
empty 16 points
First half:
empty 16 points
Second half:
empty 16 points
To Next Page
