3 - 14
3. SYSTEM CONFIGURATION
Computer link
module
AJ71UC24
*2
Link module that communicates data with a
computer.
Transmission speed: 300bps to 19.2kbps
RS-232C, RS-422: one channel each,
compatible with RS485
32 (special 32 points) 0.3 –
Maximum 6
modules can be
used for one
CPU module.
Intelligent
communication
module
AD51H-S3
AD51H-BASIC, maximum of 8 tasks executes
data communication with a PLC or a computer,
and monitoring control status.
Data communication with a computer can be
executed by any format.
RS-232C: 2 channels, RS-422, Parallel: one
channel each
48
1.0 –
Host controller
high-speed link
module
AJ71C23-S3
*2
Link module that sends/receives data at high
speed to/from a computer.
Transmission speed: 500kbps
RS-422: one channel each
32 (special 32 points) 1.5 –
Multidrop data link
module
AJ71C22-S1
Sends and receives bit data to maximum 8
slave stations to which it is connected in a
multidrop system.
Used for the master station of a multidrop link.
Transmission speed: 38.4kbps
RS-422: one channel each
32 (special 32 points) 1.4 –
A0J2C25
Used for a remote I/O station of a multidrop
link.
–––
A0J2C214(S1)
Used for a local station in a multidrop link.
In A0J2CPU and A0J2HCPU systems,
A0J2C214 can also be used as the master
station in computer links and multidrop data links
64 points 0.3 –
CC-Link system
master/local
module
AJ61QBT11
For CC-Link system master and local stations
When used as the master station, the module
controls maximum 64 remote I/O stations.
When a local station is used, the module
occupies 1 or 4 station(s).
32 (special 32 points) 0.45 –
For use with
QnACPU only
MELSECNET/
MINI-S3 data link
module
AJ71PT32-S3
For MELSECNET/MINI-S3 master stations
(max. 64 stations). Performs remote I/O and
remote terminal control of a total of 512 I/O
points.
I/O dedicated mode
32 (special 32 points)
0.34 –
AJ71T32-S3
Expanded mode
48 (special 48 points)
B/NET interface
module
AJ71B62-S3
Used for B/NET transmission terminal control.
Up to 63 stations can be controlled per module.
32 (special 32 points) 0.17 –
Interrupt module
AI61
Used to designate execution of interrupt
programs (16 interrupt inputs).
32 (special 32 points) 0.14 –
Only one
module can be
used per CPU.
AI61-S1 Product for changing time to turn ON/OFF A61
Product Name Model Name Description
Number of Occupied
Points (points)
[I/O Allocation
Module Type]
Current Consumption
Remark
5VDC(A) 24VDC(A)
First half:
empty 16 points
Second half:
special 32
points
