Mitsubishi Q2ACPU User Manual

3 - 15
3. SYSTEM CONFIGURATION
*2 This module can access devices within the device range of the AnACPU (cannot access file
register).
(Refer to Section 3.3.2)
Product Name Model Name Description
Number of Occupied
Points (points)
[I/O Assignment
Module Type]
Current Consumption
Remark
5VDC(A) 24VDC(A)
Device Net
interface
module
AJ71DN91
Device Net master module
Total I/O points: 4096 points
32 (special 32 points) 0.24 –
PROFIBUS-DP
interface
module
AJ71PB92D 32 (special 32 points) 0.54 –
PROFIBUS-
FMS interface
module
AJ71PB96F
PROFIBUS-FMS master/client/server module
Total I/O points: 241241 points
32 (special 32 points) 0.54 –
MODBUS serial
communication
module
AJ71UC24-R2
*2
MODBUS serial communication module
Transmission speed: 300bps to 19200bps
32 (special 32 points) 1.4 –
PLC easier
monitoring
module
AS91 PLC easier monitoring module 16 (16 outputs) 0.08 –
With simulation
switch 16 points
Dummy module AG62
Module allows selection of 16, 32, 48, or 64
points.
Setting range
[Input
]
0.07 –
Blank cover AG60 Dust-proof cover for unused slot 16 (empty 16 points) – – CE-compliant
PROFIBUS-DP master module
Sendable data Regular service: 32 bytes
Extension service: 244 bytes
Set number of points
