Mitsubishi Q2ACPU User Manual

3 - 16
3. SYSTEM CONFIGURATION
Product Name Model Name Description
Number of Occupied
Points (points)
[I/O Assignment
Module Type]
Current Consumption
Remark
5VDC(A) 24VDC(A)
Graphic
operation
terminal
A985GOT
Large-size graphic operation terminal
256 colors, TFT color, 800 600 dots, high
intensity
32 (special 32 points)
*
0.22
*
–
*When bus
connected
A975GOT
Large-size graphic operation terminal
256 colors, TFT color, 640 480 dots, high
intensity/256 colors, TFT color, 640 480 dots,
wide viewing angle
A970GOT
Large-size graphic operation terminal
16 colors, TFT color, 640 480 dots, high
intensity/16 colors, TFT color, 640 480 dots,
wide viewing angle/8 colors, STN color,
640 480 dots/2 colors, STN monochrome,
640 480 dots
A960GOT
Large-size graphic operation terminal
2 colors, EL, 640 400 dots
A956GOT
Medium-size graphic operation terminal
8 colors, STN color, 320 240 dots/
STN monochrome, 320 240 dots/
256 colors, TFT color, 320 240 dots, high
intensity
A956WGOT
Medium-size graphic operation terminal
256 colors, TFT color, 320 240 dots, high
intensity
A953GOT
Medium-size graphic operation terminal
8 colors, STN color, 320 240 dots/
STN monochrome, 320 240 dots/
256 colors, TFT color, 320 240 dots, high
intensity
With handheld type
–––
For RS-232C
connected only
A951GOT
Medium-size graphic operation terminal
8 colors, STN color, 320 240 dots/
STN monochrome, 320 240 dots/
256 colors, TFT color, 320 240 dots, high
intensity
32 (special 32 points)
*
0.22
*
–
*When bus
connected
A950GOT
Medium-size graphic operation terminal
8 colors, STN color, 320 240 dots/
STN monochrome, 320 240 dots/
256 colors, TFT color, 320 240 dots, high
intensity
With handheld type
–––
Dedicated to
RS-422
connection
GT1565-VTBA
Large-size graphic operation terminal
8.4"
256 colors, TFT color, 640 480 dots (When
installing a multi color display board, 65536
colors can be displayed.)
32 (special 32 points)
*
0.12 –
*When bus
connected
GT1575-VTBA
Large-size graphic operation terminal
10.4"
256 colors, TFT color, 640 480 dots (When
installing a multi color display board, 65536
colors can be displayed.)
