3. SYSTEM CONFIGURATION
Power supply module
Power
supply
slot
mouting
position
A61P
A61PN
100/200VAC input
Output: 5VDC 8A
––
A61PEU CE-compliant
A62P
100/200VAC input
Output: 5VDC 5A, 24VDC 0.8A
A62PEU CE-compliant
A63P
24VDC input
Output: 5VDC 8A
I/O slot
mounting
position
A66P
100/200VAC input
Output: 24VDC 1.2A
16 (empty 16 points)
Power supply
for AD70,
A616DAV,
A616DAI
A68P
100/200VAC input
Output: +15VDC 1.2A, -15VDC 0.7A
32
Base unit
Main
base unit
A38HB 8 I/O modules can be installed.
–––
For high-speed
access
(dedicated to
QnACPU)
A38HBEU 8 I/O modules can be installed.
For high-speed
access
(dedicated to
QnACPU)
CE-compliant
A38B 8 I/O modules can be installed.
A35B 5 I/O modules can be installed.
A32B 2 I/O modules can be installed.
No connector
for extension.
A32B-S1 2 I/O modules can be installed.
With connector
for extension.
Extension
base unit
A68B 8 I/O modules can be installed.
–––
The power
supply module
is required.
A65B 5 I/O modules can be installed.
A62B 2 I/O modules can be installed.
A58B 8 I/O modules can be installed.
–––
A61P, A61PN,
A62P,
A63P, andA65P
cannot be
mounted.
A55B 5 I/O modules can be installed.
A52B 2 I/O modules can be installed.
Extension cable
AC06B
600mm (23.62inch)
long
Cables for
connections between
base units
–––AC12B
1200mm (47.24inch)
long
AC30B
3000mm (118.11inch)
long
Product Name Model Name Description
Number of Occupied
Points (points)
[I/O Assignment
Module Type]
Current Consumption
Remark
5VDC(A) 24VDC(A)
First half:
empty 16 points
Second half:
empty 16 points
