App - 115
APPENDICES
ROR instruction
Program example:
ROR K8 ROR SD718 K8
SD718 is the device resulting from converting
accumulator A0.
SADD instruction
Program example:
LEDA SADD
LEDC D10
LEDC D100
LEDC D200
LEDR
$+ D10 D100 D200
SER instruction
Program example:
SER D10 D100 K5 SER D10 D100 SD718 K5
SD718 is the device resulting from converting
accumulator A0.
SMOV instruction
Program example:
LEDA SMOV
LEDC D10
LEDC D100
LEDR
$MOV D10 D100
SUM instruction
Program example:
SUM D10 SUM D10 SD718
SD718 is the device resulting from converting
accumulator A0.
ZRRDB instruction
Program example:
DMOV K8000 D9036
LEDA ZRRDB
DMOV K8000 SD1036
ZRRDB SD1036 SD718
SD1036 is the device resulting from converting the
special register D9036.
SD718 is the device resulting from converting
accumulator A0.
ZRWRB instruction
Program example:
DMOV K8000 D9036
LEDA ZRWRB
DMOV K8000 SD1036
ZRWRB SD1036 SD718
SD1036 is the device resulting from converting the
special register D9036.
SD718 is the device resulting from converting
accumulator A0.
An CPU Instruction
Instruction after A QnA Conversion
