App - 116
APPENDICES
AnA/AnUCPU dedicated instruction
LEDA/LEDB instruction name
SUB/LEDC device 1
......
SUB/LEDC device n
LEDR
Program example 1: SIN instruction
LEDA SIN
LEDC D10
LEDC D100
LEDR
Program example 2: DSER instruction
LEDA DSER
LEDC D10
LEDC D100
SUB K5
LEDR
Instruction name device 1 .... device n
SIN D10 D100
DSER D10 D100 SD718 K5
SD718 is the device resulting from converting
accumulator A0.
AnA/AnUCPU special function module
dedicated instruction
LEDA/LEDB instruction name
SUB/LEDC device 1
......
SUB/LEDC device n
LEDR
Program example:
LEDA SVWR1
SUB H2
LEDC D10
LEDR
Enter "G." before the instruction.
G. instruction name device Un .... device n
G.SVWR1 U 2 D10
AnA/AnUCPU data link dedicated instruction
LEDA/LEDB instruction name
SUB/LEDC device 1
......
SUB/LEDC device n
LEDR
Program example:
LEDA LRDP
SUB K12
LEDC D10
LEDC D100
SUB K5
LEDC M0
LEDR
Enter "J." before the instruction.
J. instruction name J0
device 1 .... device n
OUT SM1255
J.ZNRD J0 K12 D10 D100 K5M0
An CPU Instruction
Instruction after A QnA Conversion
Network for using MELSECNET II
