App - 117

APPENDICES

Index register

Z, Z1 to Z6, V, V1 to V6

Index register double word

ZZ0

Z1 to Z6 Z1 to Z6

VZ7

V1 to V6 Z8 to Z13

If an index register is used for destination of double

word operation or single word multiplication/division, the

relation of upper and lower levels may be broken,

causing a problem.

An CPU Instruction

Instruction after A QnA Conversion
