5 - 6
5. I/O NUMBER ASSIGNMENT
The setting details are as follows:
The items without settings are handled as follows:
Item Setting Setting range Default value
Slot setting
Set data for each slot.
(Not necessary to set all data).
Free/input/output/special
No setting
Type Set the module type.
Points Set the number of points for the module.
0 to 64 points
(in 16 point units)
Start XY Set the start number of XY devices of the module. 0 to 1FFF (in 16 point units)
Model name Set the model name of the module. Up to 16 characters
Base specification Set data for each base unit.
Up to 16 characters
No settingPower model name Set the model name of the power supply module.
Extension cable Set the model name of the extension cable. Up to 16 characters
Type and Points : In accordance with the loaded module.
Start XY : The number following the total points obtained by adding the
number of points of the modules already set.
If there is any duplication, an error (SP.UNIT LAY ERROR) is
detected.
POINT
The power supply module names set in the base specification is only used for the
current capacity check in the PLC diagnostics mode and not used for a CPU
module. Therefore, even if they are not set, any problem does not occur.
