Chapter Four: Operation External Flow Control
65
5. To configure the 247 unit to accept +1 V full scale input, set dipswitch S15 to the
settings listed in Table 15.
Dipswitch S15 Settings for +1 V Full Scale Input
Dipswitch Position
1 Open (Off)
2 Closed (On)
3 Open (Off)
4 Closed (On)
(amplifier is set to a gain of 5)
Table 15: Dipswitch S15 Settings for +1 V Full Scale Input.
6. Replace the top cover and the retaining screws.
7. Connect the pressure transducer to the controller using the proper cable.
The system interface cables are listed in Table 5, page 20.
8. Perform the steps described in
How To Setup the System,
page 55, to prepare the 247 unit
and MFCs for flow control.
