Appendix A: Product Specifications
79
Appendix A: Product Specifications
CE Compliance
Electromagnetic Compatibility
1
Low-Voltage Requirements
Installation Category
Pollution Degree
Product Safety and Liability
EMC Directive 89/336/EEC
Low-Voltage Directive 73/23/EEC
II, according to EN 61010-1
2, according to IEC 664
Product Safety Directive 92/59/EEC
Display Accuracy ±0.1% ± 1 digit
Flow Display 3 ½ Digit Display (+1.999 maximum)
Fuse Ratings
115 VAC
230 VAC
0.8 A (T) / 250 V
0.4 A (T) / 250 V
MFC Capacity 4; 1 MFC per channel, sequentially selectable
Operating Temperature 15° to 40° C (59° to 104° F)
Package ½ Rack (9.5” W x 3.5” H x 9” D)
Power Consumption 19 VA @ 115 VAC 60 Hz with no MFCs
attached
Additional
15 VA for start-up and 10 VA
operational for
each
MFC attached
Power Requirement
115 VAC Setting
230 VAC Setting
100 to 120 VAC nominal, 50/60 Hz
200 to 240 VAC nominal, 50/60 Hz
Power Supply Output Capacity ±15 VDC @ 1 Ampere
Maximum ripple < 10 mV P-P
Set Point Adjust
(each channel)
0.1 to 100% of Full Scale (flow)
0.1 to 100% of Input level (ratio)
1
An overall metal braided shielded cable, properly grounded at both ends, is required during use.
