A
endix A: Product S
ecifications
80
Signal Inputs
(each channel)
MFC
Scaling (GCF)
External Set Point
(bypasses on-board set point controls)
External ON/OFF
0 to +5 VDC (5.5 V maximum)
0.1 to 4.0
0 to 5 VDC
TTL Compatible
Signal Outputs
(each channel)
MFC Output(s)
Unscaled Transducer Output
Scaled (Corrected) Transducer Output
Minimum load impedance; 10K ohm/channel
0 to +5 VDC
0 to +1 VDC Nominal (scaled with a rear
panel scaling control); 0 to 2 VDC maximum
Weight 8.5 lbs. (3.85 kg)
Zero Correction
(each channel)
± 3% of Full Scale
Due to continuing research and development activities, these product specifications are subject to change without notice.
