MKS 670B - Table 40: Pinout of the Y-Cable 25-Pin Male Connector

I/O Connector Cables A
pp
endix D: Interface Cables for a T
yp
e 274 Multi
p
lexe
r
146
Pinout of the Y-Cable 25-pin Male Connector
Pin Signal
1
Special
2
10K
3
1K
4
100
5
10
6
1
7 No Connection
8
Channel 1 ID
9
Channel 2 ID
10
Channel 3 ID
11 Channel ID Common
12
Select Channel 1
13
Select Channel 2
14 No Connection
15 No Connection
16 No Connection
17 No Connection
18 No Connection
19 No Connection
20 No Connection
21 No Connection
22 Digital Ground
23 No Connection
24 No Connection
25 No Connection
Table 40: Pinout of the Y-Cable 25-pin Male Connector
