MKS 670B - Manual Conventions

Chapter One: General Information How This Manual is Or
g
anized
19
Manual Conventions
The following conventions apply throughout this manual:
XXXXXX
For inputs:
Indicates that the line must be pulled low to activate the
function.
XXXXXX
For outputs:
Indicates that the output is active low.
670 Front Panel Keys:
Keys on the front panel of the 670 instrument appear in
square brackets with leading spaces, for example,
Press the [
ENTER
] key.
Operating Mode
The operating mode appears in small capital letters, such as
LOCAL
mode
Knobs or Switches on the 274:
Knobs and switches on the 274 multiplexer appear in small
capital letters with leading spaces, for example:
Set the
CHANNEL SELECT
switch in the
REM
position.
