Chapter Four: Functional Overview The [SETUP] Ke
y
53
RS-232 Communication Parameters (Optional)
Note
This screen only appears when the 670 instrument is equipped with the
RS-232 remote communications option. It does not appear when the 670
instrument has the IEEE-488 communications option.
RS232: 9600 Baud
8 Bit NO Parity
Select the RS-232 communications parameters using this screen. Use an arrow key ( [ ] or
[
] ) to move through the entries. Use the Adjust knob to scroll through the options for each
entry. The default settings are: 9600 Baud, 8 Data Bits, and No Parity.
Refer to
Chapter Six: RS-232 Communications Option,
page 85, for a complete description of
the RS-232 communication parameters and protocol.
IEEE-488 Communication Parameters (Optional)
Note
This screen only appears when the 670 instrument is equipped with the
IEEE-488 remote communications option. It does not appear when the
670 instrument has the RS-232 communications option.
IEEE-488 Address: 8
Select the IEEE-488 device address using this screen. Valid addresses range from 1 to 30. Use
the Adjust knob to scroll through the addresses. The initial address is 8.
Refer to
Chapter Seven: IEEE-488 Communications Option,
page 103, for a complete
description of the IEEE-488 communication features.
