Chapter Four: Functional Overview The [TRIP POINTS] Ke
59
Latch Mode
TP A LATCH: ENABLED
TP B LATCH: DISABLED
Use the Adjust knob to select the state of the latch mode. Press the down arrow key [ ] to
set the latch for Trip Point B.
The I/O connector provides the ability to clear latched trip points remotely. Once a trip point has
been latched, you can clear the latch to release the trip point from the alarm condition, and
maintain the latch enabled mode. The trip point will become latched again should the pressure
cross a trip point.
For more information on trip points, refer to:
How To Configure the Trip Points,
on page 75
How To Disable a Trip Point,
on page 77
How To Clear a Latched Trip Point,
on page 77
How To Adjust Hysteresis,
on page 78
