Series 275 Mini-Convectron Module with DeviceNet
Instruction Manual - 275563
4.2.1 Module (MOD) LED Status
4.2.2 DeviceNet Network (NET) LED Status
Table 4-3 Series 275 DeviceNet Mini-Convectron Module LED Status
LED Status
Off No Power to the module.
Green Operating normally.
Orange The module has an unrecoverable fault, and may need to be replaced.
Flashing
Orange-Green
The module is in self test. Refer to the Identity Object in Volume II of the
ODVA DeviceNet specification.
Table 4-4 Series 275 DeviceNet Mini-Convectron DeviceNet Network Status
LED Status
Off The module is not online.
The module has not completed the Dup_MAC_ID test yet.
No power to the module.
Solid Green The module is on-line with connections in the established state.
For a Group 2 Only device, the module is allocated to a Master.
Blinking Green The module is on-line with no connections in the established state.
The module has passed the Dup_MAC_ID test, is on-line, but has not
established connections to other nodes.
For a Group 2 Only device, the module is not allocated to a Master.
Blinking Orange One or more I/O connections are in the Timed-Out state.
Orange The module has detected an error that has rendered it incapable of
communicating on the network (Duplicate MAC ID or Buss-Off).
