5 DeviceNet Operation
50
Series 275 Mini-Convectron Module with DeviceNet
Instruction Manual - 275563
5.3.3 DeviceNet Object
There is a single instance of the DeviceNet Object for the Mini-Convectron Module. No class
attributes are supported.
Table 5-17 Explicit Message Summary - DeviceNet Object
Service Class Instance Attribute
Master
data
Device
data
Data
type
Description Ty pe
0E
hex
3 1 1 None 3F USINT Get node address, range
0–63
Open
0E
hex
3 1 2 None 02 USINT Get baud rate, range 0–2 Open
0E
hex
3 1 3 None 01 BOOL Get bus-off interrupt, range
0–1
Open
0E
hex
3 1 4 None 00 USINT Get bus-off counter, range
0–255
Open
10
hex
3 1 4 0 Success Set bus-off counter Open
0E
hex
3 1 5 None 00 01 STRUCT Get allocation choice, range
0–3
Open
4B
hex
3 1 None 0B 02 Success STRUCT Set allocation choice, range
0–3
Open
4C
hex
3 1 None 03 Success BYTE Release allocation, range
0–3
Open
