5.3.4 Connection Object
There are two instances of the Connection Object in the Mini-Convectron Module. Instance #1 is
assigned to the Explicit Message Connection. Instance #2 is assigned to the Polled I/O Connection.
Table 5-18 and Table 5-19 show the attributes and the predefined values of each.
Table 5-18 Connection Object - Explicit Message Connection
Service Class Instance Attribute
Master
data
Device
data
Data
type
Description Ty pe
0E
hex
5 1 1 None 03 USINT Get state of the object, range 0–5 Open
0E
hex
5 1 2 None 00 USINT Get instance type, explicit Open
0E
hex
51 3 None83
hex
BYTE Get transport class trigger Open
0E
hex
5 1 4 None FB 05 UINT Get produced connection ID Open
0E
hex
5 1 5 None FC 05 UINT Get consumed connection ID Open
0E
hex
51 6 None21
hex
BYTE Get initial communication
characteristics
Open
0E
hex
5 1 7 None 16 00 UINT Get produced connection size Open
0E
hex
5 1 8 None 16 00 UINT Get consumed connection size Open
0Ehex 5 1 9 None C4
hex
09 UINT Get expected packet rate, range
0–65535
Open
10
hex
5 1 9 00 00 Success UINT Set expected packet rate Open
0E
hex
51 0C
hex
None 01 USINT Get watchdog timeout action, 1
or 3
Open
0E
hex
51 0D
hex
None 00 00 UINT Get produced connection path
length
Open
0E
hex
51 0E
hex
None 00 EPATH Get produced connection path Open
0E
hex
51 0F
hex
None 00 00 UINT Get consumed connection path
length
Open
0E
hex
51 10
hex
None 04 EPATH Get consumed connection path Open
