23
Available Accessories
1.5.11 MX-232-IO-Box
Order no.: MX-OPT-RS1-EXT
This box provides the signal inputs and outputs as well as
the RS232 (serial) interface. It replaces the connections
that were handled on the older camera models via a D-Sub
15-HD connector. The MX-232-IO-Box (protection class IP65,
–30 to 60 °C/–22 to 140 °F) can be attached to all MOBOTIX
cameras with an MxBus or USB interface. The maximum
length of the MxBus wiring (0.8 mm diameter wires) is 50 m/55 yd. If the MiniUSB connector
is used, the maximum cable length is 5 m/16 .
1.5.12 ExtIO Expansion Module
Order no.: MX-ExtIO
The device, which is suitable both for on-wall and in-wall
installations, contains a powerful speaker, microphone, infra-
red motion sensor, ambient temperature sensor, two input
and two output contacts and two illuminated keys. It is ideal
for door communication, elevators, access control systems,
etc. The ExtIO is suitable for use as direct connection to the
S15 via a MiniUSB cable (max. 5 m), which can be ordered
separately, or as a network connection via the PoE switch.
1.5.13 Mx2wire+ Media Converter
Order no.: MX-2wirePlus-Set-PW
The Mx2wire+ system allows an Ethernet network with PoE
to be set up via two-wire cables, which saves users from
having to lay several hundred meters of Ethernet cable. For
example, an existing two-wire cable of an analog video cam-
era can be reused to connect a high-resolution and modern
IP network camera. Mx2wire+ is delivered in the standard
wall outlet frame in dierent designs; however, it can also
be used with the available on-wall socket that is included.
