M26 Camera Manual: Operating the Camera
3.3.3 SpecialCongurationintheBrowser
Thanks to its hemispherical lens, the MOBOTIX M26 provides certain special conguration
options for the image settings. Depending on where the camera is mounted (ceiling or wall)
and on the live image display preferred by the user, certain important basic settings and, if
necessary, their adjustment must be congured when a M26 is rst installed.
CongurationoftheM26BasicParameters
Complete the steps described below in the browser window:
1. Log onto the camera and boot it as described in Section 3.2, «First Images and the
Most Important Settings».
2.
Selectmountingpositionwall/ceiling/oor: Click on Installation in the Quick Control
panel and then select Wall, Ceiling or Floor according to the mounting position of the
camera. Ceiling always means that the orientation of the camera or sensor module
is from
top to bottom and for Floor, the camera or sensor module’s orientation is
from
bottom to top .
As a result, you will get a perspective-corrected panorama view for each image sensor
matching the specied mounting position. Panorama view is set as a factory default
and it can be changed as described below.
3. Switch to the Display Mode Quick Control.
4. Set the mode that you want to be the standard view. For demonstration purposes,
the descriptions below describe the typical display mode for the wall mount and the
ceiling mount, Panorama and Surround respectively. Every other display mode can
be operated in the same way.
