M26 Camera Manual: Product Overview
1.4.2 Dimensions for Wall Installation
1.4.3 Dimensions for Ceiling Installation
^
106.5 mm/4.19 in
140.5 mm/5.53 in
112 mm/4.41 in
106.5 mm/4.19 in
39 mm/1.54 in
189 mm/7.44 in
115.5 mm/4.55 in
222 mm/8.74 in
90°
20°
72 mm/2.83 in
106.5 mm/4.19 in
106.5 mm/4.19 in
27 mm/1.06 in
137 mm/5.39 in
140.5 mm/5.53 in
156 mm/6.14 in
59 mm/2.32 in
115.5 mm/4.55 in
72 mm/2.83 in
90°
20°
