Delivered Parts and Dimensions
Caution
Only use
original MOBOTIX cable
to connect the camera. Standard cables purchased
from other suppliers do not meet the necessary specications for proper protection
(no longer weatherproof according to IP66).
MiniUSB cableEthernet patch cable
Replacing the Cable Retainer
Insert the cable into the receptacle on the camera. Position the bayonet catch from the side
(opening points to the right). Rotate the bayonet catch clockwise to the “lled circle” sym
-
bol (see gure). The cable is now properly retained.
MOBOTIX patch cables are
available as accessories
in dierent lengths (1 m,
2 m, 5 m and 10 m)
Close the cable retainer by
rotating the bayonet catch
to the marked position
Bayonet catch
closed
