M26 Camera Manual: Installation
2.7 Network and Power Connection
2.7.1 Notes on Cable Lengths and Power Supply
•
Power is supplied to the camera via the camera Ethernet connection (patch or installation
cable). We recommend using a MOBOTIX PoE adapter or another similar high-quality
PoE product to loop-in the power supply:
– One camera: with the PoE adapter (MX-NPA-PoE or MX-NPA-Box)
– Multiple cameras: with PoE products conforming to IEEE 802.3af (PoE switch)
• The maximum length of the network cable for power supply over an Ethernet cable
is 100 m.
•
Make sure that you only use switches or routers that support the 10/100 Mbps network
interface of the camera.
• We highly recommend using uninterruptible power supplies (UPS) to provide backup
power.
• If you are using IEEE 802.3af or IEEE 802.3at (PoE+) Power-over-Ethernet network
components to supply power to MOBOTIX cameras, make sure, if possible, that these
components do not have a fan. Since the power consumption of MOBOTIX cameras is
very low compared to other products, the reliability of the entire system is increased,
thus extending the life of these components.
Caution
Max. power consumption of attached extension modules: The power consumption
of all attached
MxBus modules
must
not exceed 2.5 W
. When attaching modules to
the MxBus connector
and
the USB socket, the
power consumption of all attached
modules must not exceed 3 W
,
if the camera is powered by PoE class 3
. If
PoE class 2
is used,
the camera cannot power any peripheral devices!
For information on changing the PoE class, see Section 2.7.8, «Variable PoE».
2.7.2 Network Cabling For M26 With Patch Cables
Using a patch cable and an MX-Overvoltage-Protection-Box or MX-NPA-Box oers the fol-
lowing advantages:
• Quick installation/deinstallation
• No shortening of cable even when installing/deinstalling several times
• Hose-proof/dust-proof connection in accordance with IP66
• Additional protection against overvoltages of up to 4 kV when using the
MX-Overvoltage-Protection-Box.
