EMC INDUSTRIAL GROUP LTD I/O Function Table
MW93A_IM_ALL_SV6.09f_en 53/59
Output Functions
48 pulse output‡ 0
49 1
50 * 2
51 3
52 4
53 * 5
54 in volumetric mode 6
55 * speed demand set 7
56 run motor 8
57 running 9
58 paused 10
59 material feed 11
60 healthy 12
61 fault 13
62 alarm 14
63 alarm alert 15
Status1
Output Functions
64 setpoint disturbance 0
65 holding flowrate 1
66 holding control 2
67 minimum setpoint control 3
68 low flow cutout 4
69 weight disturbance 5
70 tune control 6
71 calibration indicator 7
72 8
73 * user bit 3 9 Ϯ
74 * user bit 4 10 Ϯ
75 * user bit 5 11 Ϯ
76 * user bit 6 12 Ϯ
77 timer output 13
78 clock active 14
79 daylight saving time 15
Status2
Output Functions
80 limit 1 output 0
81 limit 2 output 1
82 limit 3 output 2
83 in remote flowrate mode 3
84 4
85 5
86 6
87 7
88 8
89 IN0 9
90 IN9 10
91 OUT0 11
92 OUT9 12
93 MO3 fitted 13
94 disable macros 14
95 MR1 connected 15
Status3
Output Functions
96 IN1 0
97 IN2 1
98 IN3 2
99 IN4 3
100 IN5 4
101 IN6 5
102 IN7 6
103 IN8 7
104 OUT1 8
105 OUT2 9
106 OUT3 10
107 OUT4 11
108 OUT5 12
109 OUT6 13
110 OUT7 14
111
output function
OUT8 15
IOx
In most cases, IO Function bits are set and reset by the controller or the digital input
signals.
MODBUS
The registers control1, control2, control3, status1, status2, status3, IOx, faults,
control4 and IOx2 can all be read over modbus.
The registers control2, control3, control1C and control1G can be written to over
modbus.
Bits marked Ϯ can also be set by writing their bit number to the IO Control register
(address 8038). Writing the negative value of the number will reset the bit. For
example writing -14 to 8038 will reset ‘user bit 1’. (write 14 to set)
MACROS
IO Function bits 1 to 187 can be set & reset using the SET_BIT, CLEAR_BIT and
TOGGLE_BIT instructions.
The IF instruction can test bits 1 to 150.
This register hold the state of inputs IN1 to IN8 and outputs OUT1 to OUT8.
The status of IN0, IN9, OUT0 and OUT9 are in the status3 register
