eMux Connector Function Connector Type
RF output connector – 2 TNC connector
RF output connector – 3 TNC connector
RF output connector – 4 TNC connector
Power Supply Connector External Power Supply
Table 4: eMux Connector Specification
Specification Type Description
Part Numbers:
Indoor:
EMX-3004-W
EMX
-
3004
-
EW
Outdoor:
EMX-3004-WO
EMX
-
3004
-
EWO
Frequency:
865
–
928 MHz
Maximum Power Consum
ption:
10 Watts
Maximum DC Power Supply:
130 Watts
Power:
24 VDC input
Power Supply:
115 VAC input; 24 VDC, 5.41 A output (EMX-3004-W
Model)
230 VAC input; 24 VDC, 5.41 A output (EMX-3004-EW
Model)
Dimensions (L x W x H):
10.5” x 6.25” x 1.5” (26.7cm x 15.9cm x 3.8cm)
Weight:
2.5 lbs (1.1 kg)
Operating Temperature:
-
30°C to +60°C
Storage Temperature:
-
40°C to +85°C
Humidity:
5 – 95% non-condensing
Regulatory:
FCC Part 15, EN 60950, EN 50364, EN 301 489-1
EN 301 489
-
3, EN 302 208
-
2
Maximum RF Out
put Power:
22 dBm
Maximum Gain:
30 dB
Physical Interfaces:
Input: 1 TNC female
Output: 4 TNC female
DC Input: 5
-
Pin Circular
Indicators:
Power, Status
