STAR™ 3000 / eNode3000 User Manual
Mojix Incorporated
Page
32
www.mojix.com
(877) 886-6549
Figure 23: Redundant Power Supplies
Once the MCON hardware is mounted and secured, and prior to issuing power to the unit,
connect a network cable to the eth0 port as identified in the figure below. The next step is to
power on the unit.
Figure 24: Identification of Network Interfaces
