10 System Network Setup
The MCON has the flexibility to configure and manage the STAR unit through an internet-based
interface called the Web Console.
10.1 Connecting to the MCON
The MCON by default uses DHCP for IP assignment. If a DHCP server is not found within 5
minutes from power up, the MCON uses the following default IP address:
• Default Static IP: 169.254.1.1
• Default Netmask: 255.255.0.0
• Default Gateway: 169.254.1.1
It is recommended to connect the MCON, using loopback/crossover cable, directly to a
Windows PC for the initial setup. This will ensure that the MCON defaults to the IP address
above after 5 minutes. If the MCON is instead connected to a LAN with DHCP server, it may
acquire a different IP address – making it difficult to locate on the network for first time setup.
10.2 Changing MCON Network Settings
The simplest way to change network settings of the MCON is to navigate a web browser to the
MCON’s IP address. Use the following credentials to authenticate the connection:
User: edison
Password: m0j1xInc
Once connected, click on the Configuration pull-down menu and select Network. The following
figure shows the Network configuration page. The user can choose between DHCP or a static
IP address. Once changes are made, click on the Save button. Changes occur within 30
seconds.
