3.2.2 Wall mounted traverse system
A wall mounted system is mounted on separate
wall brackets, wall mounted rails or on brackets
connected to uprights supported by the wall and
the floor.
1. Primary rails mounted on separate wall
brackets.
2. Primary rails mounted on brackets connected
to uprights supported by the wall and the
floor.
3. Primary rails mounted on wall rails.
Figure: Wall mounted rail with wall brackets
