Traverse trolleys
MRS Traverse trolleys are used in all traverse sys-
tems which uses H-profile as primary rails. Comes
in two versions, Standard and lowered 50mm.
Delivered in a complete set with two trolleys.
51
206
Primary Rail
Article no.
110 9550 Traverse trolley set (grey)
110 959 0 Traverse trolley set (white)
101
206
Primary Rail
Article no.
110 9570 Traverse trolley set 50mm+ (grey)
110 95 8 0 Traverse trolley set 50mm+ (white)
Boxed traverse trolleys
Boxed traverse trolleys have lower building height,
and curtain pass through (CPT) version (with bog-
gie wheels) can be used in rail systems with gap
for curtains.
224
13
Primary Rail
Article no.
110 9592 Boxed traverse trolley set, white
110 9593 Boxed traverse trolley set, grey
110 959 6 Boxed traverse trolley CPT set, white
1109597 Boxed traverse trolley CPT set, grey
Figure: Curtain pass through.
4.4 Traverse Trolleys
