Molift Rail System / www.molift.com
3.3.2 Climbing systems
Molift Nomad is suitable for climbing (room to
room transfer) between two rails system
Figure: Room to Room transfer with Portable
motor Molift Nomad.
3.3.3 Hatch in door opening.
With a hatch in the dooropening, hoist can move
freely from room to room.
A
A=100mm
Figure: Hatch in door opening for Molift Nomad.
A
B=100mm
A=250mm
B
C= Rail Height (62/112/142mm)
Figure: Hatch in door opening for Molift Air.
