APPENDIX
DS2000 USER’S MANUAL (rev.C)
A.4
3.204 Functionality added:
• DRIVE OK signal is present also without DC BUS and NO BUS fault is activated
only if trying to enable the drive
• NOTCH FILTER can be enabled with I2T PROTECTION active
Functionality removed:
• ACC/DEC features
3.205 Functionality added:
- G motors algorithm always running, also while braking
3.206 Special software for the V/f control
3.207 Special software version for high performance applications. Option card needed.
Functionality added:
• Position resolution variable from 10 to 16 bits depending on the motor speed
• External reference 14 bits A/D converted
• Encoder simulated output from 64 to 16384 pulses
Functionality removed:
• Encoder feedback is not available
• ENC/OUT calibration of marker zero
3.208 Special software designed for encoders without absolute U-V-W signals
3.209 Special software designed for 300A power stage size E drive
3.210 Special software designed for 300A power stage size E drive and to manage 4
different motor parameter sets selectable through 2 external inputs. Option card
needed.
Functionality added:
• None
Functionality removed:
• Encoder feedback is not available
• ENC/OUT calibration of marker zero
• Notch filter
4.100 Special software used in CAN Open options (speed mode). Option card needed.
Make reference to the CAN Open DS2000 manual (GB-4540).
4.100
NTC
Special software used in CAN Open options (speed mode). Option card needed.
NTC motor sensor version. Make reference to the CAN Open DS2000 manual
(GB-4540).
