SECTION TWO – WIRING AND INSTALLATION
DS2000 USER’S MANUAL (rev.C)
2.10
2.7 FANS
DS2000 ventilation is provided by one or more fans mounted over the drive and under only
for size E. The fans input power is internally supplied except for size E (option “internal 24V”)
CAUTION: A free air circulation must be ensured for a proper operation as per the following
table..
DS2000
Size
Minimum Clearence Top
(mm)
Minimum Clearence Bottom
(mm)
A 60 100
B 60 100
C 80 160
D 100 200
E 200 300
Tab. 2.5A – Minimum Clearence around DS2000 Drives
2.8 RESET OR RESTART BUTTON
The reset (restart) button is on the drive front panel. It allows the digital control card re-
initialization as well as the protections reset.
