SECTION SIX – COMMANDS
DS2000 USER’S MANUAL (rev.C)
6.5
6.2.2 RESOLVER PARAMETERS POLES
RESOLVER PARAM. POLES=
Description: it indicates the resolver poles number
Allowed values:
from 2 to 24 in 2 unit steps
Note: set the values indicated on the nameplate of
the motor or refer to the data indicated on the mo-tor
catalogue
Attention: available only with resolver feedback
mode
ENC.OUT.PULSES CONFIGURATION=
Description: it indicates the number of encoder
pulses output on J2C connector
Allowed values:
from 64 to 1024 pulses for resolver polar couple in
power of 2n
Note: drive generates output pulses dividing the input
pulses anyway used for motor control
Attention:
- available only with resolver feedback mode
- to set a new configuration it is necessary to save
and reboot
ZERO LENGTH=
Description: it indicates the marker width for drive
electric loop measurement output on J2C connector
Allowed values:
• 90°
• 180°
• 360°
Note: drive generates output pulses dividing the input
pulses anyway used for motor control
Attention:
- available only with resolver feedback mode
- to set a new configuration it is necessary to save
and reboot
6.2.3 ENCODER PARAMETERS DESCRIPTION
MOTOR PARAMETERS ENCODER=
Description: it indicates the number of motor
encoder pulses
Allowed values:
from 1024 to 8192 in 512 unit steps
Note: set the values indicated on the nameplate of
the motor or refer to the data indicated on the motor
catalogue.
Attention: available only with encoder feedback
mode
