Moog Matriarch User Manual

67
(Continued)
Global Parameters
Group 3
Group Select
Key
Parameter
Select Key
Sync Enable
Button Blinks
3.3 KB CV OUT Range F#2 F#0 3 x / 3 x
The Matriarch keyboard generates a specific control voltage for every note played. The voltage range of this
signal appears at the KB CV OUT jack on the Matriarch rear panel, and can be set to (-5V to +5V) or (0V to
+10V) in order to accommodate another synthesizer or piece of electronic music gear. Use the first two white
keys to select either -5V to +5V (C0), or 0V to +10V (D0). The Default is -5V to +5V.
3.4 Arp/Seq CV OUT Range F#2 G#0 3 x / 4 x
The Matriarch Arpeggiator and Sequencer generate a specific control voltage for every note played. The
voltage range of this signal appears at the CV OUT jack in the ARP / SEQ module on the front panel, and can
be set to (-5V to +5V) or (0V to +10V) in order to accommodate another synthesizer or piece of electronic
music gear. Use the first two white keys to select either -5V to +5V (C0), or 0V to +10V (D0). The Default is
-5V to +5V.
3.5 KB VEL OUT Range F#2 A#0 3 x / 5 x
The Matriarch keyboard generates a specific control voltage based on the dynamics of every note played. The
voltage range of this signal appears at the KB VEL OUT jack on the rear panel, and can be set to (0V to +5V)
or (0V to +10V) in order to accommodate another synthesizer or piece of electronic music gear. Use the first
two white keys to select either 0V to +5V (C0), or 0V to +10V (D0). The Default is 0V to +5V.
3.6 Arp/Seq VEL OUT Range
F#2 C#1 3 x / 6 x
The Matriarch Arpeggiator and Sequencer generate a specific control voltage based on the dynamics of every
note played. The voltage range of this signal appears at the VEL OUT jack in the ARP / SEQ module on the
front panel, and can be set to (0V to +5V) or (0V to +10V) in order to accommodate another synthesizer or
piece of electronic music gear. Use the first two white keys to select either 0V to +5V (C0), or 0V to +10V (D0).
The Default is 0V to +5V.
3.7 KB AT OUT Range F#2 D#1 3 x / 7 x
The Matriarch keyboard generates a specific control voltage based on the amount of Aftertouch being
applied. The voltage range of this signal appears at the KB AT OUT jack on the rear panel, and can be set to
(0V to +5V) or (0V to +10V) in order to accommodate another synthesizer or piece of electronic music gear.
Use the first two white keys to select either 0V to +5V (C0), or 0V to +10V (D0). The Default is 0V to +5V.
3.8 MOD WHL OUT Range F#2 F#1 3 x / 8 x
The Matriarch Modulation (MOD) Wheel generates a specific control voltage based on its current position.
The voltage range of this signal appears at the MOD WHL OUT jack on the rear panel, and can be set to
(0V to +5V) or (0V to +10V) in order to accommodate another synthesizer or piece of electronic music gear.
Use the first two white keys to select either 0V to +5V (C0), or 0V to +10V (D0). The Default is 0V to +5V.

Moog Matriarch Specifications

General

Product type	Analog synthesizer
Sound effects	Delay
Sound effects quantity	1
Keyboard number of keys	49
Maximum polyphony (notes)	4
MIDI in	Yes
6.35 mm (1⁄4-inch) input	3
6.35 mm (1⁄4-inch) output	2
Input voltage	240 V
DC input voltage	12 V
Power source type	DC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	361 mm
Width	810 mm
Height	139 mm
Weight	13610 g
