SYSTEM
Replacing Blade Sets
6. Insert the Blade Extractor Tools, one at each end of the Blade Set, as shown in
FIG 33.1 below.
7. Lever the Blade Assembly in the direction shown in FIG 33.2 to unclip and release the
Blade Set.
FIG 33.1
FIG 33.2
Note The Position of The
Blade Extractor Tool
Under The Lip of The
Blade Adjuster Assembly
