Page 35
SYSTEM
Replacing Blade Sets
13. Refit the Sheet Guide Assembly
14. Close the top cover
15. Switch the machine on and test the crease for form.
The following Blade sets are supplied with the Digifold 5000P as standard.
Consisting of a standard blade and anvil, pre-set for your machine.
Standard Blade set Part number 176-213-02
Narrow Blade set Part number 176-213-01
Consisting of a standard blade and a narrow anvil, pre-set for your machine.
NOTE.
Blade sets are individually set for each machine at the point of manufacture.
Replacement Blade sets will therefore need to be set up by a factory trained service
engineer.
Do not attempt to use a Blade set from another Digifold 5000P.
Socket Head
Blade Adjustment
Blade Adjustment
Assembly
Cam
Screw
Digifold 5000P
