GENERAL CARE AND MAINTENANCE
31
Nurse call / Ethernet Test: The ports on the back of the device (nurse call/ethernet) are tested at a different
voltage as defined below. The negative (black) connection of the tester should be connected to the DC Power
Input via TF0571 (or equivalent). The positive (red) lead wire is connected to TF0570.
Connection
Test Connector/Method
Nurse Call/Ethernet
TF0570
Item
Value
Unit of Measure
Boundary
Applied Potential
1000
Volts DC
Minimum
Ramp Time
3.0
Seconds
Minimum
Dwell Time
1.0
Seconds
Minimum
Current High
0.500 (500 uA)
mA
Maximum
Current Low
0.0
mA
Minimum
AC Hi-pot Testing
Applies to all of the following optional patient inputs (applied parts) installed on the monitor being tested. Test
connectors are required to properly connect test equipment to the applied part inputs to perform Hi-pot testing.
The negative (black) connection of the tester should be connected to both the Line and Neutral on the AC side
of the external AC/DC Power Module (Item # 4101-012), typically by utilizing tool TF-0107. The positive
(red) lead wire is connected to the connection defined below.
The ECG input should be tested separately, and the other applied parts (SpO2, Temp, CO) can be connected
together via a shorting bar (as shown in the diagram below) to expedite the testing process. This is not a
requirement and the tests can be performed separately.
Connection
Test Connector/Method
ECG
Patient cable 9293-050-60 and shorting bar
SpO2
TF0281
Temp 1, Temp 2
TF0559
Cardiac Output
TF0558
Item
Value
Unit of Measure
Boundary
Applied Potential
3000
Volts AC
Minimum
Ramp Time
3.0
Seconds
Minimum
Dwell Time
1.0
Seconds
Minimum
Current High
0.500 (500 uA)
mA
Maximum
Current Low
0.0
mA
Minimum
For Brazil testing, dwell time is increased to 60 seconds.
