Motion 3000ES Escalator Control
32 Manual # 42-02-E001
Table 10. Controller Parameters
Param Name Description Value Default MCE
FUN1-Logic Input Settings
F1-01 Contact on Brake
Set the correct polarity of Brake Con-
tact or to disable this feature
0=NC
1=NO
2=Disable
1
F1-02
Contact on Auxil-
iary brake
Set the correct polarity of Auxiliary
brake contact or to disable or to cancel
this feature
0=NC
1=NO
2=Cancel
3=Disable
2
F1-03
Upper entry
detection switch
With VVVF drive & energy-saving con-
trol, upper entry detecting switch input
setting
0=NC
1=NO
1
F1-04
Lower entry
detection switch
With VVVF drive & energy-saving con-
trol, lower entry detecting switch input
setting
0=NC
1=NO
1
FUN2- Timer Menu
F2-01 Oil timer interval Oil ---- time interval setting 0-9999 min 120
F2-02
Oil Timer dura-
tion setting
Oil ---- duration setting 0-9999 sec 6
F2-03 Speed Pick Delay
In VVVF drive mode, delay from brake
picked to motor run mode. Program to
1000 for VVVF application.
In ATL mode, this feature is not used.
Program to default setting 1000
In Wye/Delta mode, delay from brake
picked to Wye contactor Closed. Pro-
gram to 500 for Wye/Delta application
0-9999 millisec 1000
F2-04
Up/Dn to Delta
delay
Wye/Delta only. Delay from Wye con-
tactor enable to Delta contactor enable
0-9999 millisec 1000 1000
F2-05
Month /Date Set-
ting
System time setting: Month /Date MM/DD 0000 Month/Date
F2-06
Hour/Minute Set-
ting
System time setting: Hour/Minute (24-
hour clock)
HH/MM 0000 Hour/Minute
F2-07
Reduced Speed
Timer
Duration setting from high speed to low
speed operation
1-9999 sec
0=disabled
60
F2-08 Auto-Stop Timer
Duration setting from low speed opera-
tion to stop/standby. If set to “0”, F4-05
automatic direction switching is dis-
abled.
1-9999 sec
0=disabled
0
F2-09
Handrail Over-
speed Delay
Delay time of the speed fault checking
for left and right handrail
0-9 sec 4 4
F2-10
Smoke Detector
Delay
Delay time setting for fire alarm fault
inspection
0-30 sec 15 15
F2-11
Alarm Timer at
start
Alarm bell output time setting before
the Escalator start
0-9 sec 1 1
