Motion Control Engineering Motion 3000ES

Operating Adjustments
33
F2-12 Stop Delay
PM Contactor and Brake drop delay set-
ting.
Program to 900msec for VVVF drive/
ATL and 0 sec for Wye/Delta.
If system is equipped with Motor Effi-
ciency Controller, set to 200.
0-5000Msec 500
F2-13
Y/D Open Transi-
tion Timer
Wye-Delta Open Transition Timer 0-5000Msec 0 100
F2-14
Alarm Shutoff
Timer
Alarm Bell output Shutoff Timer 0-60 min 0 10
FUN3- Speed Monitoring
F3-01 Step speed S2
Terminal S2 on EC-MCB: Speed check-
ing 1 for step wheels/direction
0-9999 units 1
Learned
Speed check-
ing 1 for step
speeds
F3-02 Step speed S3
Terminal S3 on EC-MCB: Speed check-
ing 2 for step wheels/direction
0-9999 units 1
Learned
Speed check-
ing 2 for step
speeds
F3-03
Left handrail
speed S4
Terminal S4 on EC-MCB: Speed check-
ing for left handrail
0-9999 units 1
Learned
speed check-
ing for Left
handrail
F3-04
Right handrail
speed S5
Terminal S5 on EC-MCB: Speed check-
ing for right handrail
0-9999 units 1
Learned
speed check-
ing for Right
handrail
F3-05 Step speed S6
Terminal S6 on EC-SCB: Speed check-
ing 1 for step wheels
0-9999 units 1
Learned
Speed check-
ing 1 for step
speeds
F3-06 Step speed S7
Terminal S7 on EC-SCB: Speed check-
ing 2 for step wheels
0-9999 units 1
Learned
Speed check-
ing 2 for step
speeds
F3-07
Left handrail
speed S8
Terminal S8 on EC-SCB: Speed check-
ing for left handrail
0-9999 units 1
Learned
speed check-
ing for Left
handrail
F3-08
Right handrail
speed S9
Terminal S9 on EC-SCB: Speed check-
ing for right handrail
0-9999 units 1
Learned
speed check-
ing for Right
handrail
F3-09 Speed error on S2
Set Upper and Lower speed limit for S2
using the percentage of value of F3-01.
0-99% 15 15
F3-10 Speed error on S3
Set Upper and Lower speed limit for S3
using the percentage of value of F3-02.
0-99% 15 15
F3-11 Speed error on S4
Set Upper and Lower speed limit for S4
using the percentage of value of F3-03.
0-99% 15 15
F3-12 Speed error on S5
Set Upper and Lower speed limit for S5
using the percentage of value of F3-04.
0-99% 15 15
Table 10. Controller Parameters
Param Name Description Value Default MCE
