Motion Control Engineering Motion 3000ES

Motion 3000ES Escalator Control
34 Manual # 42-02-E001
F3-13 Speed error on S6
Set Upper and Lower speed limit for S6
using the percentage of value of F3-05.
0-99% 15 15
F3-14 Speed error on S7
Set Upper and Lower speed limit for S7
using the percentage of value of F3-06.
0-99% 15 15
F3-15 Speed error on S8
Set Upper and Lower speed limit for S8
using the percentage of value of F3-07.
0-99% 15 15
F3-16 Speed error on S9
Set Upper and Lower speed limit for S9
using the percentage of value of F3-08.
0-99% 15 15
F3-17
Missing step on
EC-MCB
Top missing steps detecting by S2, S3
on EC-MCB
0-9999 0
Enter same
as learned
value of
parameter
F3-01
F3-18
Missing step on
EC-SCB
Bottom missing steps detecting by S6,
S7 on EC-SCB
0-9999 0
Enter same
as learned
value of
parameter
F3-05
F3-19
Self-learned stop-
ping distance
Learned stopping distance. Not avail-
able on all software versions.
0-9999 0
Set automati-
cally
F3-20
Stopping dis-
tance error
Sets upper and lower stopping distance
limit using the percentage of value of
F3-19. Not available on all software
versions.
0-99% 0
F3-21
Missing step at
low speed
VVVF systems only. Scales learned step
speed so that missing step can be
detected at low speed during energy
saving mode. Not available on all soft-
ware versions.
0-99% 0
FUN4- Advanced Configuration
F4-01 Motor control
Selects VVVF/ATL or Wye/Delta drive
mode
0=VVVF or ATL
1= Wye/Del
0
F4-02
Arrow display
mode
Display mode of the EC-DISP Board
0=big arrow
1=small arrow
00
F4-03 EC-SCB enable
Determines if the EC-SCB board is used
for control redundancy (read) or not.
0=No
1=Yes
11
F4-04 Oil device type Type of the oil device
0=motor
1=electromag-
netic Valve
11
F4-05
Energy saving
mode
Determines escalator automatic speed
mode selection (VVVF drive only).
0= Normal
(Single speed)
1= Energy Sav-
ing (2 spd, start-
ing direction
only)
2= Intelligent (2
spd, 2 direc-
tions based on
entry detect)
0
F4-06
Rev insp enable
on EC-MCB
Applied reversal inspection on EC-MCB
or not
0=No
1= Yes
01
Table 10. Controller Parameters
Param Name Description Value Default MCE
