Operating Adjustments
35
F4-07
Rev detect enable
on EC-SCB
Applied reversal detection on EC-SCB
or not
0=No
1= Yes
01
F4-08
Pulse phase dif-
ference on EC-
MCB
Pulse phase difference on EC-MCB.
Automatically set when a self-learn
operation is run for this processor. See
F4-10.
0 – 99 0
Set automati-
cally
F4-09
Pulse phase dif-
ference on EC-
SCB
Pulse phase difference on EC-SCB
Automatically set when a self-learn
operation is run for this processor. See
F4-11.
0 - 99 0
Set automati-
cally
F4-10
Self-learn on EC-
MCB
Used to enable a self-learn operation
for the EC-MCB board.
0=disabled
1=enabled
10
F4-11
Self-learn on EC-
SCB
Used to enable a self-learn operation
for the EC-SCB board.
0=disabled
1=enabled
10
F4-12
P2(Run) enable
on EC-MCB
P2 (“RUN”) on EC-MCB is used or not
0=No
1=Yes
1
F4-13
Fault latch set-
ting P9-P27
Faults Latch or Unlatch
A=P9, P10, P11 B=P12, P13, P14,
C=P15, P16, P17 D=P18, P24, P27
0=Latch
1-7 = Unlatch
0 0 0 0
D C B A
5017 (See
note following
table)
F4-14
Fault latch set-
ting P28-P37
Faults Latch or Unlatch
A=P28, P29, P30 B=P31, P32, P33,
C=P34, P36, P37 D= N/A, N/A, N/A
0=Latch
1-7 = Unlatch
0 0 0 0
D C B A
0101 (See
note following
table)
F4-15 Escalator number
Escalator ID for remote monitoring.
Not available on all software versions.
0-9999 0 0
F4-16 P9 Enable
Programmable error message:
1. Reverse Phase
2. Speed Governor
3. Reverse Phase or MEC Fault
4. MEC fault
Not available on all software versions.
1-4 1 1
F4-17 P24 Enable
Programmable error message:
1. Seismic Fault
2. Tandem Fault
3. Broken Belt
4. Brake Wear
5. Broken Step Chain
6. Brake Overheat
7. Speed Governor
Not available on all software versions.
1-6 1 1
F4-18 P36 Enable
Programmable error message:
1. Broken Step Chain
2. Tandem Fault
3. Broken Belt
4. Brake Wear
5. Pit Flooded
6. Brake Overheat
Not available on all software versions.
1-6 1 1
Table 10. Controller Parameters
Param Name Description Value Default MCE
