Motion Control Engineering Motion 3000ES

Motion 3000ES Escalator Control
48 Manual # 42-02-E001
Table 16. KEB Function Selection
Value State Value State Value State
0 No Function Active 2
Energy Saving Up all Speeds
Active
8
Line Contactor Enabled for
High Speed Up Operation.
1
Energy Saving Down Low
Speed Active
4
Line Contactor Enabled for
High Speed Down Operation
To select more than one function, add the respective numbers together and enter the total value.
Table 17. KEB Input Status
Value State Value State Value State
0 No Inputs Active. 68 Low Speed and Up Active 137
High Speed, Enable, and
Down Active
1 Enable Active 69
Low Speed, Enable, and Up
Active
192 Inspection Speed Active
2 Reset Active 72 Low Speed and Down Active 193
Inspection Speed and
Enable Active
4Up Active 73
Low Speed, Enable, and
Down Active
196
Inspection Speed and Up
Active
5 Up and Enable Active 128 High Speed Active 197
Inspection Speed, Enable,
and Up Active
8Down Active 129
High Speed and Enable
Active
200
Inspection Speed and Down
Active
9 Down and Enable Active 132 High Speed and Up Active 201
Inspection Speed, Enable,
and Down Active
64 Low Speed Active 133
High Speed, Enable, and Up
Active
65
Low Speed and Enable
Active
136 High Speed and Down Active
