Disassembly/Reassembly Procedures: Radio Reassembly 7-27
7.6.9 Reassemble Multi Function Knob (22)
1. Align the D-shaped part of the shaft with the D-shaped hole on the Multi Function knob. Press
the knob into place.
Figure 7-40. Reassemble the Multi Function Knob
7.6.10 Reassemble the Antenna (23)
1. With the radio turned off, turn the antenna clockwise to attach it to the radio.
Figure 7-41. Attaching the Antenna
