GETTING STARTED

Radio Parts and Controls

The Bluetooth Pairing Location Indicator is for future enhancement of the Bluetooth feature.

These radio controls/buttons are programmable.

E5 Control Head

Emergency

(Orange)

Button

Menu Select

Buttons

LED

Indicators

4-Way Navigation

Buttons

Button

Volume

Knob

Power

Button

Accessory Port

(Microphone)

Mode

Knob

Screen

Display

Bluetooth

Pairing Location

Indicator

Dimmer

Button

Home

Button

Main Page
